Specifications

  • Camera

  • Image Sensor
    • 1/2.8" 4K Exmor CMOS
  • Effective Picture Elements
    • 8 Megapixels
  • Output Resolutions
    • 4K/30 (IP/UVC only), 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 720p/60, 720p/59.94, 720p/50, 720p/30
  • Minimum Illumination
    • 0.7 lux (IRE50, F1.6, 30fps)
  • S/N Ratio
    • ≥ 50 dB
  • Gain
    • Auto, Manual
  • Shutter Speed
    • 1/1 to 1/10,000 sec
  • Exposure Control
    • Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
  • White Balance
    • Auto, Manual
  • Optical Zoom
    • 30X
  • Viewing Angles
    • DFOV: 75.5° (Wide) to 3.1° (Tele)
    • HFOV: 68.0° (Wide) to 2.7° (Tele)
    • VFOV: 41.7° (Wide) to 1.5° (Tele)
  • Focal Length
    • f = 4.3 mm (Wide) to 129 mm (Tele)
  • Aperture (Iris)
    • F = 1.6 (Wide) to 4.7 (Tele)
  • Minimum Working Distance
    • 0.01 m (Wide), 1.2 m (Tele)
  • Pan / Tilt Angles
    • Pan: ±170°, Tilt: +90° / -35°
  • Pan / Tilt Speed (Manual)
    • Pan: 0.1° to 100° / sec, Tilt: 0.1° to 100° / sec
  • Preset Speed
    • Pan: 200° / sec, Tilt: 200° / sec
  • Preset Positions
    • 10 (IR), 256 (RS-232 / IP)
  • Camera Control - Protocols
    • VISCA (RS-232 / IP), PELCO-D & PELCO-P (RS-232), CGI (IP)
  • Image Processing
    • Noise Reduction (2D / 3D), Flip, Mirror, WDR, BLC
  • Power Frequencies
    • 50 Hz, 60 Hz
  • Speaker

  • Embedded Speaker
    • Yes
  • SPL
    • 77 dB SPL (1W / 1m)
  • Maximum SPL
    • 90 dB SPL at 0.5 m
  • Microphone

  • Built-in Microphone
    • 2 (Omnidirectional)
  • AI Noise Reduction
    • Yes
  • Pickup Range
    • 5 m
  • Sensitivity
    • -33 dBFS
  • Frequency Response
    • 20 Hz to 20 KHz
  • Maximum SPL
    • 133 dB SPL at 0.5 m
  • Loop Recording

  • Resolution
    • Up to 4K
  • Length of Video
    • 5 minutes
  • Recording Modes
    • Loop & continuous
  • Loop Mechanism
    • Wipe the oldest clip
  • Interface

  • Video Outputs
    • HDMI, IP, USB
  • Audio Outputs
    • HDMI, IP, USB
  • General

  • Power Requirement
    • AC 100 - 240V to DC 12V/3.34A
  • Power Consumption
    • 36W
  • Dimensions (W x H x D)
    • 168.0 x 205.0 x 126.0 mm
  • Net Weight
    • 1.95 kg
  • Application
    • Indoor
  • Tally Lamp
    • N/A
  • Security
    • Kensington Slot
  • Remote Control
    • Infrared
  • Operating Conditions
    • Temperature: 0 °C to +35 °C
    • Humidity: 20% to 80%
  • Storage Conditions
    • Temperature: -20 °C to +60 °C
    • Humidity: 20% to 95%
  • IP Streaming

  • Resolution
    • 4K 30fps
  • Network Video Compress Formats
    • H.264, H.265
  • Maximum Frame Rate
    • 4K 30fps
  • Network Interface
    • 10 / 100 / 1000 Base-T
  • Multi-Stream Capability
    • 2 (RTSP / Web Page), 4K 30fps (max.)
  • Network Protocols
    • IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP
  • USB

  • Connector
    • USB 3.0
  • Video Format
    • MJPEG, YUY2
  • Audio Format
    • PCM
  • USB Video Class (UVC)
    • UVC 1.1
  • USB Audio Class (UAC)
    • UAC 1.0
  • Software Tools

  • IP Search and Configuration Tool
    • Support Windows® 7 or later
  • Warranty

  • Camera
    • 3 Years
  • Accessories
    • 1 Year
  • Package Contents
    • Camera, Remote Control, Power Adapter, Power Cord, Screws (x2), USB Cable, Quick Start Guide

* Specifications may vary depending on countries and are subject to change without notice.
