Camera theo dõi tự động DL30

Đặc tính kỹ thuật

Camera

Image sensor
- 1/2.8" 1080p Low Lux CMOS
Effective Picture Elements
- 2 Megapixels

Output Resolution
- 1080p/60 (IP Streaming & USB)
Minimum Illumination
- 0.5 Lux (IRE50, F1.6, 30fps)

S/N Ratio
- > 50 dB
Gain
- Auto, Manual

TV Line
- 800 (Center), 600 (Corner)
Shutter Speed
- 1/4 to 1/10,000 sec (60 Hz)
- 1/3 to 1/10,000 sec (50 Hz)

Exposure Control
- Auto, Manual, WDR
WDR
- Yes

White Balance
- Auto, Manual
Optical Zoom
- 12X

Digital Zoom
- 2X
Viewing Angles
- DFOV : 84.1° (Wide) to 7.8° (Tele)
- HFOV : 76.5° (Wide) to 6.8° (Tele)
- VFOV : 47.3° (Wide) to 3.8° (Tele)

Focal length
- f = 3.9 mm (Wide) to 46.8 mm (Tele)
Aperture (Iris)
- F = 1.6 (Wide) to 2.8 (Tele)

Minimum Working Distance
- 0.3 m (Wide), 1.5 m (Tele)
Pan / Tilt Angles
- Pan : ±170°, Tilt : ±90°

Pan / Tilt Speed (Manual)
- Pan: 1° to 90°/sec
- Tilt: 7.85° to 45°/sec
Preset Speed
- Pan : 120° / sec, Tilt : 110.84° / sec

Preset Positions
- 10 (IR), 256 (IP & USB)
Camera Control - Interface
- IP, USB

Camera Control - Protocol
- VISCA (IP), CGI (IP), USB
Image Processing
- Noise Reduction (2D/3D), Flip, Mirror, WDR

Power Frequency
- 50Hz / 60Hz

AI Auto Tracking Functions

Tracking Modes
- Presenter Mode, Zone Mode, Hybrid Mode

Privacy Protection Mechanisms

Protection Modes
- Privacy Mode, Sleep Mode

Audio

Channels
- 2ch (Stereo)
Codecs
- AAC, PCM

Sample Rate
- AAC (48/32/16/8 KHz), PCM (48 KHz)

Interface

Video Outputs
- IP, USB
Audio Outputs
- IP, USB

Audio Inputs
- Mic in, Line in

General

Power Requirement
- AC 110–220V to DC 12V/2A
Power Consumption
- 12W

PoE
- PoE+
Dimensions (W x H x D)
- 158.8 x 200.0 x 162.2 mm

Net Weight
- 1.62 (±0.1) kg
Application
- Indoor

Tally Lamp
- N/A
Security
- Kensington slot

Remote Control
- Infrared
Operating Condition
- Temperature: 0°C to 40°C
- Humidity: 20% to 80%

Storage Condition
- Temperature: -20°C to 60°C
- Humidity: 20% to 95%

IP Streaming

Resolution
- 1080p 60fps
Network Video Compress Format
- H.264, MJPEG (Web Page)

Network Audio Compression Formats
- AAC
Sample Rates
- 48, 32, 16, 8 KHz

Maximum Frame Rate
- 1080p 60fps
Bit-rate Control Modes
- VBR, CBR

Range of Bit-rate setting
- 512 Kbps to 32 Mbps
Network Interface
- 10/100 Base-T

Multi-stream Capability
- 2 (1 for IP Streaming, 1 for Web Page), (1 for USB, 1 for Web Page),1080p 60fps (max.)
- 3 (1 for IP Streaming, 1 for Web Page, 1 for USB), 1080p 30fps (max.)
Network Protocol
- IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP / RTCP, RTSP, RTMP, VISCA over IP

NDI^®|HX Capability
- N/A

Connector
- USB 3.1 Gen 1 Type-B
Video Formats
- MJPEG, YUY2

Maximum Video Resolution
- 1080p
USB Video Class (UVC)
- UVC1.1

USB Audio Class (UAC)
- UAC1.0

Web UI

Live Video Preview
- Yes
Camera PTZ Control
- Pan / Tilt / Zoom / Focus / Preset Control

Camera / Image Adjustment
- Exposure / White Balance / Picture
Network Configuration
- DHCP, IP Address, Gateway, Subnet Mask, DNS

Software Tools

IP Search and Configuration Tool
- Supports Windows^® 7 or later
PTZ Management
- Supports Windows^® 7 or later

PTZ Control Panel
- Supports iOS & iPadOS^® 9 or later
CaptureShare
- Supports Windows^® 7 or later, macOS^® 10.14 or later

PTZ Link
- Supports Windows^® 7 or later, macOS^® 10.14 or later

Warranty

Camera
- 3 Years
Accessories
- 1 Year

Package Contents
- Camera, Remote Control, Power Adapter, Power Cord, USB Cable, Cable Ties (x4), Cable Fixing Plate (x1), M2 x 4mm Screws (x2), 1/4"-20L 7.5mm Screw (x1), Quick Start Guide
Optional Accessories
- "Wall Mount Kit (Brackets (x2), M4 x 8mm Screws (x2), 1/4"-20L 7.5mm Screw (x1), Wall Mount Kit Installation Guide), Ceiling Mount Kit (Brackets (x2), M3 x 6mm Screws (x3), 1/4"-20L 7.5mm Screws (x3), Ceiling Mount Kit Installation Guide)"
