DL10
Camera tự động theo dõi trong giảng dạy

• Camera

• Image Sensor

  • 1/2.8" 1080p Low Lux CMOS

• Effective Picture Elements

  • 2 Megapixels

• Output Resolutions

  • 1080p/60 (IP Streaming & USB)

• Minimum Illumination

  • 0.5 Lux (IRE50, F2.0, 30fps)

• S/N Ratio

  • ≥ 50 dB

• Gain

  • Auto, Manual

• TV Lines

  • 800 (Center/Wide)

• Shutter Speed

  • 1/4 to 1/10,000 sec (60 Hz)
  • 1/3 to 1/10,000 sec (50 Hz)

• Exposure Control

  • Auto, Manual, WDR

• WDR

  • Yes

• White Balance

  • Auto, Manual

• Optical Zoom

  • 3X

• Digital Zoom

  • 2X

• Viewing Angles

  • DFOV: 90° (Wide) to 35.8° (Tele)
  • HFOV: 82° (Wide) to 31.7° (Tele)
  • VFOV: 51° (Wide) to 17.9° (Tele)

• Focal length

  • f = 3.3 mm (Wide) to 9.7 mm (Tele)

• Aperture (Iris)

  • F = 2.0 (Wide) to 3.7 (Tele)

• Minimum Working Distance

  • 0.5 m (Wide), 1.0 m (Tele)

• Pan/Tilt Angles

  • Pan : ±170°, Tilt : ±90°

• Pan/Tilt Speed (Manual)

  • Pan: 1° to 100°/sec
  • Tilt: 10.8° to 100°/sec

• Preset Speed

  • Pan : 200°/sec, Tilt : 200°/sec

• Preset Positions

  • 10 (IR), 256 (IP & USB)

• Camera Control - Interfaces

  • IP, USB

• Camera Control - Protocols

  • VISCA (IP), CGI (IP), USB

• Image Processing

  • Noise Reduction (2D/3D), Flip, Mirror, WDR

• Power Frequencies

  • 50 Hz, 60 Hz

• AI Auto Tracking Functions

• Tracking Modes

  • Presenter Mode, Zone Mode, Hybrid Mode

• Gesture Control

  • Yes (Tracking On/Off, Full/Upper Body)

• Privacy Protection Mechanisms

• Protection Modes

  • Privacy Mode, Sleep Mode

• Audio

• Channels

  • Line in: 2ch Stereo
  • Mic in: Mono

• Codecs

  • AAC-LC (48, 32, 16, 8K), PCM (48K)

• Sample Rates

  • 48, 32, 16, 8 KHz

• Microphones

• Built-in Microphones

  • 2 (Omnidirectional)

• Noise Suppression

  • Yes

• Pickup Range

  • 5 m

• Sensitivity

  • -33 dBFS

• Frequency Response

  • 30 Hz to 20 KHz

• Maximum SPL

  • 129 dB SPL at 0.5 m

• Interface

• Video Outputs

  • IP, USB

• Audio Outputs

  • IP, USB

• Audio Inputs

  • Line in, Mic in

• General

• Power Requirement

  • AC 100 - 240V to DC 12V/2A

• Power Consumption

  • 11W

• PoE+

  • N/A

• Dimensions (W x H x D)

  • 92.4 x 164.0 x 94.4 mm

• Net Weight

  • 0.76 kg

• Application

  • Indoor

• Tally Lamp

  • N/A

• Security

  • Kensington Slot

• Remote Control

  • Infrared

• Operating Conditions

  • Temperature: 0°C to 40°C
  • Humidity: 20% to 80%

• Storage Conditions

  • Temperature: -20°C to 60°C
  • Humidity: 20% to 95%

• IP Streaming

• Resolution

  • 1080p 60fps

• Network Video Compress Formats

  • H.264, MJPEG (Web Page)

• Network Audio Compression Formats

  • AAC-LC

• Sample Rates

  • 48, 32, 16, 8 KHz

• Maximum Frame Rate

  • 1080p 60fps

• Bit-Rate Control Modes

  • VBR, CBR

• Bit-Rate Range Setting

  • 512 Kbps to 32 Mbps

• Network Interface

  • 10/100 Base-T

• Multi-Stream Capability

  • 2 (1 for IP Streaming, 1 for Web Page), (1 for USB, 1 for Web Page),1080p 60fps (max.)
  • 3 (1 for IP Streaming, 1 for Web Page, 1 for USB), 1080p 30fps (max.)

• Network Protocols

  • IPv6, IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, DHCP, RTP/RTCP, RTSP, RTMP, VISCA over IP

• NDI^®|HX Capability

  • N/A

• USB

• Connector

  • USB 3.1 Gen 1 Type-B

• Video Formats

  • MJPEG, YUY2

• Maximum Video Resolution

  • 1080p

• USB Video Class (UVC)

  • UVC 1.1

• USB Audio Class (UAC)

  • UAC 1.0

• Web UI

• Live Video Preview

  • Yes

• Camera PTZ Control

  • Pan, Tilt, Zoom, Focus, Preset Control

• Camera / Image Adjustment

  • Exposure, White Balance, Picture

• Network Configuration

  • DHCP, IP Address, Gateway, Subnet Mask, DNS

• Software Tools

• IP Search and Configuration Tool

  • Supports Windows® 7 or later

• PTZ Management

  • Supports Windows® 7 or later

• PTZ Control Panel

  • Supports iOS & iPadOS® 9 or later

• OBS Plugin for PTZ Cameras

  • Supports Windows® 8 or later, macOS® 10.13 or later

• CaptureShare

  • Supports Windows® 7 or later, macOS® 10.14 or later

• Warranty

• Camera

  • 3 Years

• Accessories

  • 1 Year

• Package Contents

  • Camera
  • Remote Control
  • Power Adapter
  • Power Cord
  • USB Cable
  • Cable Ties (x3)
  • Cable Fixing Plate
  • M2 x 4mm Screws (x2)
  • 1/4"-20L 7.5mm Screw (x1)
  • Quick Start Guide

• Optional Accessories

  Wall Mount Kit

  • Brackets (x2)
  • M4 x 8mm Screws (x2)
  • 1/4"-20L 7.5mm Screw (x1)
  • Wall Mount Kit Installation Guide

  Ceiling Mount Kit

  • Brackets (x2)
  • M3 x 6mm Screws (x3)
  • 1/4"-20 L7.5mm Screws (x3)
  • Ceiling Mount Kit Installation Guide

  Tripod

* Specifications may vary depending on location and are subject to change without notice.
